Heavy Duty De-Raker Double Vernier Shroud Adjuster For Higher Load Applications Ø5mm

Vernier or stay adjuster with 2 rows of holes for finer tuning and a de-raker plate. The de-raker plate allows quick and safe rake adjustment as the shroud is always retained. The shroud is attached to the de-raker by a swaged fork. It is retained in the vernier adjuster by a clevis pin in the top hole. Rake is then adjusted using two detent or fast pins that engage in the slots in the de-raker plate. This allows safe rake adjustment ashore or afloat with no risk that de-attaching the shroud could cause the mast to fall over. Rake adjustment is in 4mm increments with 18 numbered holes for easy and quick replication of rig settings. This assembly uses our Mk2 version of the vernier unit with thicker plate to prvent bending under higher loads. Overall width has also been reduced to the miniumum required for the derkaer plate. Pins are made from high strength stainless steel to resist bending and denting. A front hole is provided at the top of the adjuster to attach a lacing hook or other devise to retain a spinnaker halyard. Another use is to attach shockcord that loops around and then supports the spinnaker sheet ratchet block. Supplied with 2 detent (fast) pins and 2 clevis pins/rings.
