Valley Side Entry Cleat (Starboard) in Aluminium 1-6 mm line

The Valley Side Entry Cleat (Starboard) in Aluminium is designed for handling lines between 1-6 mm with side entry access for added convenience. The aluminium construction provides durability and prevents rope burn under high loads.

The cleat can be used with a tapered pad (sold separately) to adjust the angle for better rope alignment. The side entry feature allows for quick and easy line insertion, making it ideal for applications where fast adjustments are required. Can be mounted on flat or curved surfaces using rivets, countersunk screws or bolts.

Max line size: 6 mm
Min line size: 1 mm
Hole spacing: 66 mm
Mounting: 2xM5
Weight: 30 g
